Fetal Monitor YR02190B
Fetal Monitor YR02190B — equipo de laboratorio Kalstein con especificaciones técnicas, características avanzadas y soluciones profesionales certificadas para uso científico.
The Fetal Monitor YR02190B is an advanced medical device designed to accurately monitor fetal heart rates and uterine contractions. With a vibrant 5.7-inch color display and a resolution of 800x600, this monitor delivers clear, real-time waveforms. It supports up to six waveforms and comes with essential configurations such as FHR1, TOCO, FM, and recorder. Optional advanced features include a fetal stimulator, FHR2, and a convenient trolley for mobility. The device’s special DSP system and modern recognition ensure precise signal processing, making it a trusted choice for healthcare professionals. Empower your practice with precise fetal monitoring by requesting a quote today through the Kalstein Plus platform.
Market Pricing
The price range for fetal monitors like the YR02190B varies significantly, typically from $1700 to $2500, influenced by brand reputation, included features, and additional technical specifications. The competitive price and superior features of the YR02190B make it an excellent investment for medical facilities looking to enhance their fetal monitoring capabilities.
Frequently Asked Questions
How accurate is the fetal heart rate measurement? The monitor boasts a measurement range of 50 to 240 bpm with a precise accuracy of 1bpm.
Can this device be used in a home setting? While possible, the YR02190B is primarily designed for clinical environments due to its complexity and advanced features.
Advantages and Disadvantages
Advantages: This device offers high accuracy and reliability with advanced signal processing technologies. It facilitates better monitoring with a user-friendly interface.
Disadvantages: The initial setup may require professional guidance, and ongoing maintenance is necessary to ensure long-term accuracy.
Field Usage
The Fetal Monitor YR02190B is primarily utilized in maternity and obstetrical care settings. Its precise monitoring capabilities provide healthcare providers with invaluable data for assessing fetal well-being during prenatal visits and labor management.
Recommendations
To ensure the longevity and effectiveness of the YR02190B, regular maintenance checks are recommended. Users should receive thorough training to take full advantage of its extensive features and functionalities.
Features
- 5.7-inch color display with 800x600 resolution
- Support for up to 6 waveforms
- Includes FHR1, TOCO, FM, and recorder
- Optional features like fetal stimulator, FHR2, and trolley
- Advanced DSP system for accurate signal processing
Technical Specifications
| Model | YR02190B |
| FHR | |
| Strength | < 5mW/cm2 |
| Working Frequency | 1.0MHz |
| Signal Processing | Special DSP system and modern recognition |
| Measurement Range | 50～240bpm |
| Alarm Range | High Limit: 160, 170, 180, 190 bpm Low Limit: 90, 100, 110, 120 bpm |
| Maximum Audio Output Power | 1.5 Watt |
| TOCO | |
| Working mode | Pressure transducer |
| TOCO measurement range | 0-100 Relative (%) |
| Resolution | 1 count |
| Non-linear error | 8% |
| AUTO FETAL MOVEMENT (AFM) | |
| Technique | Pulse Doppler Ultrasound |
| Measurement range | 0%-100% |
| Resolution | 1% |
| ECG | |
| ECG waveform | Manual control ECG waveform display |
| ECG falls off | Detect automatically |
| Heart Rate Measurement Range | 15bpm-300bpm |
| Accuracy | 1bpm |
| Sp02 | |
| Measurement range | 0-100% |
| Resolution | 1% |
| Accuracy | 90-100% 1% / 7%-90% 2% |
| Pulse Rate Measurement range | 20~300 bpm |
| Accuracy | 1bpm |
Technical specifications
| Dimensions | L 29 × W 24 × H 91 cm |
|---|---|
| Weight | 5 kg |
| Manufacturer | Kalstein |
Video Fetal Monitor YR02190B
Frequently asked questions
How to know the prices of Fetal Monitor YR02190B?
To know the price of Fetal Monitor YR02190B, please send us an email with your request through the contact form AQUI.
What are the delivery times for Fetal Monitor YR02190B?
Delivery time depends on stock availability and freight type (air or sea). In stock: air 15-30 days, sea 45-60 days. Out of stock: air 30-60 days, sea 60-90 days.
How to make a purchase of Fetal Monitor YR02190B?
You can buy by email ([email protected]), phone (+33 (0) 1 70 39 26 50) or through the official Kalstein website in your country.
How does the warranty work for Fetal Monitor YR02190B?
All Kalstein equipment comes with a 1-year warranty against manufacturing defects. The warranty does not cover damage from improper installation or misuse. See our «terms and conditions» AQUI.
Can I request a quote online for Fetal Monitor YR02190B?
Yes, you can request a quote for the Kalstein equipment you are interested in directly from our official website. Click AQUI.
