12-Lead ECG monitor USB / RS232 interface YR05160

The 12-Lead ECG monitor USB / RS232 interface YR05160 is a state-of-the-art electrocardiograph capable of simultaneously capturing 12-lead ECG signals and printing ECG waveforms through a thermal printing system. This advanced EKG machine is crucial for identifying abnormal heart rhythms and investigating the causes of chest pain by recording the heart's electrical activity. The heart's small electrical impulses, which cause it to contract, are detected effectively by this ECG machine, providing accurate and timely results for healthcare professionals.

Market Pricing

In the competitive landscape of ECG machines, the 12-Lead ECG monitor USB / RS232 interface YR05160 falls within a moderate to premium price range. Depending on the supplier and additional features, prices can vary from $800 to $2,500. For specific pricing details, it is advisable to request a quote through our platform to obtain the most accurate and competitive pricing options available today.

Frequently Asked Questions

What is the primary use of the YR05160 ECG monitor? The primary use is to monitor and record the electrical activity of the heart, helping detect irregularities and assess cardiac health. How easy is it to operate? The YR05160 is designed for user-friendly operation, suitable for both professional medical settings and clinical environments. Is technical support available? Yes, comprehensive technical support is available to assist users in set-up, operation, and troubleshooting.

Advantages and Disadvantages

The main advantages of the 12-Lead ECG monitor USB / RS232 interface YR05160 include high accuracy, reliable performance, and ease of integration with existing systems using its USB or RS232 interface. However, some users may find the initial setup process complex without prior technical knowledge.

Field Use

In real-world applications, this ECG monitor proves invaluable across hospitals, clinics, and research facilities. Its capability to provide detailed ECG readings helps in timely diagnosis and tracking of patient heart health, making it an essential device for medical practitioners.

Recommendations

To maximize the efficiency and lifespan of the YR05160, regular calibration and maintenance are recommended. Ensure the device is stored in a safe environment to avoid unnecessary wear and tear.

Features

• Simultaneous 12-lead ECG signal collection
• Thermal printing system for clear ECG waveforms
• User-friendly interface for easy operation
• USB / RS232 interfaces for seamless connectivity

Technical Specifications

Model	YR05160
Guide	12 standard conductors
Calibration voltage	: 1mV ± 2%
Voltage tolerance	≥ ± 500mV
Constant time	≥3.2s
Frequent response	0.05 ~ 160Hz (-3db)
Noise level	<15μVp-p
Sensitivity valve	≤20μV
Sensitivity	2.5, 5, 10, 20mm / mV
Interchannel interference	≤0.5mm
Paper speed	6.25, 12.5, 25, 50mm / s (± 3%)
Input dynamic range	± 10Vpp
Filter: AC Filter	50Hz / 60Hz
