Description
The YR456 Floating Workstation is designed to provide a complete and efficient solution for slide processing in histology and pathology laboratories. This device features a pure green digital screen that allows real-time monitoring of the heating temperature, offering direct and clear operation. All parameters, including preset temperatures, working temperatures, and operational status, are displayed in real-time, facilitating simple and precise operation.
Temperature is automatically controlled by single-chip microprocessors. Additionally, the new heating mechanism uses a high thermal conductivity heating element, ensuring fast and uniform heating. The PID control and triple temperature controls guarantee a long lifespan, safety, reliability, and energy savings. Temperature measurement accuracy is achieved through integrated detection blocks made in the USA. All settings are automatically stored in the system, offering uninterrupted operation.
Market Price
The price of the YR456 Floating Workstation varies depending on the supplier and additional specifications. Generally, these high-quality systems range from $2,000 to $4,000 USD. This investment reflects the advanced technology and precise features of the YR456, making it a valuable option for laboratories that require consistent, high-quality results.
Frequently Asked Questions
- What is the temperature range of the water bath?
The temperature range of the water bath is from room temperature to 70℃, maintained automatically.
- Is the YR456 easy to operate and maintain?
Yes, its intuitive design and digital screen make both operation and maintenance straightforward.
Advantages and Disadvantages
Advantages:
- Fully programmable computer control for automatic start and stop.
- Fast and uniform heating with low energy consumption.
- Five individually controlled heating zones for maximum efficiency.
- High precision in temperature control (±2%).
- Paraffin flow control via touch plate and optional foot pedal.
Disadvantages:
- It may require a significant initial investment.
- Its size and weight can be a challenge for laboratories with limited space.
- Product Use in the Field
In practical applications, the YR456 Floating Workstation is used for efficient and precise slide processing in histology and pathology laboratories. The heated zones, including the paraffin chamber, paraffin dispenser, left and right thermal storage compartments, and heating plate, operate independently, preventing interference and improving efficiency. The cryogenic plate temperature can be adjusted thanks to a new type of inverter compressor, facilitating tissue freezing, especially for small samples.
Recommendations
To ensure optimal performance of the YR456, it is recommended to follow the manufacturer’s instructions for regular maintenance and calibration. Properly training personnel in the correct use of the system is also essential to achieve consistent results and extend the device’s lifespan.
Discover how the YR456 Floating Workstation can improve efficiency and precision in your laboratory. Request a personalized quote or generate an automatic quote through Kalstein Plus today. Elevate the quality of your slide processing and optimize your workflow with our advanced laboratory solutions.
Technical Specifications
| Model | YR456 |
| Left Temperature range of water bath | RT – 70℃; automatically maintained |
| Right Temperature range of water bath | RT – 70℃; automatically maintained |
| Temperature range of slide dryer | RT – 100℃; automatically maintained |
| Automatic memory and restoration functions | After startup, all preset temperature data
are automatically stored in the system. |
| Temperature Control Precision | ±2℃ |
| Dimensions of water bath dish | 155×155×55mm(W×D×H) |
| Dimensions of drying station(32pcs slides) | 405×130mm(W×D×H) |
| Working Voltage | AC 220V±10% 50Hz (standard model); AC110V±10% 60Hz |
| Power | 600W |
| Dimensions | 475×460×175 mm (W×D×H) |
| Net weight | 10kg |
