Cryostat Microtome YR426-1

The Cryostat Microtome YR426-1 is an essential tool in the medical field for the rapid analysis of pathological sections of human, animal, and plant tissues. This advanced device is widely used in hospitals, medical schools, forensic medicine, and animal and plant research units. The YR426-1 consists of four main parts: the top part houses the microcomputer control and panel operation, the central part includes a low-temperature freezer for rapid tissue freezing, the bottom part contains the compressor cooling unit, and the rear part handles mechanical transmission and motor drive. The 10-inch color LCD touchscreen of the YR426-1 provides a clear and user-friendly interface. It displays critical parameters such as the total number of cuts, cut thickness, temperature control, and date and time. Additionally, its ability to switch between Chinese and English operating interfaces facilitates its use worldwide. Moreover, the humanized hibernation function allows controlling the freezer compartment temperature between -1 and -9 °C. Once the hibernation is canceled, it quickly reaches the cutting temperature within 15 minutes.

Market Price

The Cryostat Microtome YR426-1 has a price range between $20,000 and $32,000 USD, depending on the supplier and additional specifications. This investment reflects the advanced technology and precise features of the device. Thus, it is a valuable option for laboratories and hospitals that require fast and high-quality tissue analysis results.

Frequently Asked Questions

• What is the temperature range of the YR426-1 chamber?

The temperature range of the YR426-1 chamber varies between 10℃ and -50℃.

• Is the YR426-1 easy to operate and maintain?

Yes, the intuitive design and touchscreen make both operation and maintenance straightforward.

Advantages and Disadvantages

Advantages:

• Precise temperature control thanks to advanced microprocessors.
• 10-inch color LCD touchscreen for easy operation.
• Hibernation function for energy savings.
• Dual compressors for efficient cooling.
• Self-check function for the temperature sensor.

Disadvantages:

• It may require a significant initial investment.
• Its size and weight can be challenging for laboratories with limited space.

Product Use in the Field

In practical applications, the Cryostat Microtome YR426-1 is used to obtain rapid and precise pathological sections in histology and pathology laboratories. The dual compressors enable efficient cooling of the freezing box, freezing table, knife holder, sample holder, and tissue press. Additionally, the device features an ultraviolet disinfection system to ensure a hygienic working environment.

Recommendations for Optimal Performance

To maximize the performance of the YR426-1, follow the manufacturer's instructions for regular maintenance and calibration of the equipment. Properly training personnel in the correct use of the system is also essential to achieve consistent results and extend the device's lifespan. Discover how the Cryostat Microtome YR426-1 can enhance efficiency and precision in your laboratory. Request a personalized quote or generate an automatic quote through Kalstein Plus today. Elevate the quality of your tissue analysis and optimize your workflow with our advanced laboratory solutions.

Technical Specifications

Model	YR426-1
Chamber Temperature	10℃ ～ -50℃
Freezing shelf temperature	0℃ ～ -50℃
Temperature control range of sample chuck	10℃ ～ -50℃
Additional semiconductor refrigeration in the freezer	-60℃
Number of freezing station	36 pcs
Pelletier number	8 pcs
Semiconductor fast cooling working time	15 minutes
Maximum specimen size	55mm×80mm
Vertical stroke	65mm
Horizontal stroke	22mm
Electric feed speed	0.9mm/s、0.45mm/s
Disinfection method	UV
Section thickness range	0.5μm～100μm Adjustable 0.5μm～5μm Increment0.5μm 5μm～20μm Increment1μm 20μm～40μm Increment2μm
Trimming thickness range	10μm～600μm Adjustable 10μm～50μm Increment5μm 50μm～100μm Increment10μm 100μm～600μm Increment50μm
Specimen retraction	0～100μm Adjustable，Increment5μm
Extra Advantages
The 10-inch color LCD touch screen can separately display the total number of slices and the total slice thickness, slice thickness, specimen retraction value, temperature control, date, time, temperature, timing sleep switch, defrost and other functions. The operation display can be set to switch between Chinese and English operation interface, which is convenient for different users all over the world to operate.
Humanized hibernation function: After selecting the hibernation state, the temperature of the freezer compartment can be automatically controlled between -1 and -9°C. After the hibernation is canceled, the sectioning temperature can be reached within 15 minutes.
Imported dual compressors refrigerate the freezing box, freezing table, knife holder, sample chuck, and tissue presser at five points respectively.
Equipped with rubber instrument rack and waste box
X-axis 360°, Y-axis 12°universal rotation, snap-on tissue chuck, easier and faster to install the organization
The knife holder is equipped with a blade thruster and a knife guard to cover the full length of the blade, which protects the user safely.
Anti-adhesive tissue flattening device, with specimen refrigeration, the temperature can reach -50°, which is convenient for freezing the tissue and saving operation time
The temperature sensor self-checking function can automatically detect the working status of the sensor
Hand wheel positioning 360° locking function at any point
Single-layer heated glass door, effectively preventing water mist condensation
The sample chuck travels to the limit position and automatically returns to the starting position function
Dimension size(mm)	700×760×1160mm
Weight	135 KGS
