Description
The Benchtop pH/Conductivity/DO Meter YR06385 is a cutting-edge analytical device engineered for accurate measurement and monitoring of pH, conductivity, and dissolved oxygen (DO) levels. Featuring a 7-inch colored capacitive touch screen, this advanced meter offers high-resolution display combined with user-friendly operation. Its built-in microprocessor facilitates intelligent functions such as automatic calibration, automatic temperature compensation (ATC), extensive data storage, and wireless capabilities including Bluetooth and USB output for seamless data transfer. With an impressive capability to store up to 1000 sets of test data, this meter ensures that precise analytical results are readily available whenever needed.
Market Price
In the market, benchtop pH/Conductivity/DO meters like the YR06385 typically range from approximately $1500 to $2300 USD. This price range reflects the superior technology and extensive capabilities offered by these types of analytical instruments, positioning the YR06385 as a competitive option for laboratories and industries seeking precision and reliability in their measurements.
Frequently Asked Questions
- Can the device be connected to a computer? Yes, the YR06385 supports PC connectivity via USB and Bluetooth for real-time data transfer.
- How many calibration points does it support? The pH mode supports 1, 2, and 3-point calibration with automatic recognition of 25 buffers.
- What is the storage capacity of the device? The meter can store up to 1000 sets of test data, easily transferable to a USB memory stick for further analysis.
Advantages and Disadvantages
Advantages: The YR06385 offers high accuracy with its advanced calibration functions and intelligent data management. Its user-friendly interface and wireless connectivity enhance its flexibility and convenience. The smart electrode status display ensures the precision of all measurements.
Disadvantages: The initial setup may require some technical knowledge to fully utilize all its features, and it may represent a significant investment for smaller labs or operations limited by budget constraints.
Field Use
The YR06385 is ideal for use in various applications, including environmental monitoring, water quality testing, and laboratory research. Its ability to measure pH, conductivity, and DO in a single device simplifies operations, allowing users to obtain and manage comprehensive data efficiently.
Recommendations
To maximize the lifespan and accuracy of the YR06385, regular calibration and electrode maintenance are recommended. Keep the electrodes clean and properly stored when not in use. With its high sensitivity, the meter should be operated within the specified working conditions to maintain precision and reliability. For optimal results, we encourage users to experience the benefits of the YR06385 by requesting a quote or generating an automatic quote through the Kalstein Plus platform.
Features
- 7-inch colored capacitive touch screen with high resolution and high sensitivity.
- Intelligent microprocessor with automatic calibration and data storage capabilities.
- Supports wireless Bluetooth printing and real-time data transfer to mobile devices.
- Smart electrode status display for accuracy assurance.
- Large data storage capacity, able to store 1000 sets of test data.
Technical Specifications
| Model | YR06385 | |
| pH | Measurement range | (-1.999 ~ 19.999)pH |
| Resolution | 0.1/0.01/0.001 pH | |
| Accuracy | Electrode: ±0.002 pH, Meter: ±0.01 pH | |
| Input current | ≤1×10-12 A | |
| Input impedance | ≥3×1012 Ω | |
| Stability | ±0.002 pH/3h | |
| Temperature compensation | (0 ~ 100)ºC, auto or manual | |
| mV | Measurement range | -1999.9mV ~ 0 ~ 1999.9mV |
| Resolution | 0.1 mV | |
| Accuracy | ±0.03% FS | |
| Conductivity | Measuring range | Conductivity: |
| (0.00~20.00)μS/cm | ||
| (20.0~200.0)μS/cm | ||
| (200~2000)μS/cm | ||
| (2.00~20.00)mS/cm | ||
| (20.0~200.0)mS/cm | ||
| (200~2000)mS/cm(K=10) | ||
| TDS:(0 ~ 100)g/L | ||
| Salinity:(0 ~ 100)ppt | ||
| Resistivity:(0 ~ 100)MΩ·cm | ||
| Resolution | 0.01/0.1/1μS/cm; 0.01/0.1mS/cm | |
| Accuracy | Electrode: ±0.5% FS, Meter: ±0.8% FS | |
| Temp. compensation range | (0 ~ 50)ºC, auto | |
| Electrode constant | 0.1/0.5/1/5/10/50/100 cm-1 | |
| Reference Temp. | 25ºC,20ºC,18ºC | |
| DO | Measuring range | (0 ~ 20.00)mg/L(ppm) (0 ~ 200.0)% |
| Resolution | 0.1/0.01 mg/L(ppm) 1/0.1 % | |
| Accuracy | Electrode: ±0.10 mg/L, Meter: ±0.40 mg/L | |
| Response time | ≤30s (25ºC, 90%response) | |
| Residual current | ≤0.1 mg/L | |
| Temp compensation | (0 ~ 45)ºC (automatic) | |
| Salinity compensation | (0 ~ 45) ppt (automatic) | |
| Pressure compensation | (80 ~ 105) kPa (automatic) | |
| Automatic calibration | Air saturated by water; water saturated by air | |
| Electrode type | Polarographic | |
| Temperature | Range | (-10 ~ 110)ºC |
| Resolution | 0.1ºC | |
| Accuracy | 5 ~ 60ºC:±0.4ºC Others: ±0.8ºC | |
| Other Parameters | Display | 7-inch colored capacitive touch screen |
| Data storage | 2000 sets | |
| Power | 12V (110-220, 50-60Hz adapter) | |
| Communication interface | USB, RS232, Bluetooth | |
| Dimensions&Weight | 240×170×70mm/600g | |
| Working Conditions | Temperature | 15 ~ 30 ºC |
| Humidity | ≤85% | |
| IP grade | IP54 | |
