Microscope Trinocular YR0241

The Laboratory Microscope YR0241 is a state-of-the-art optical instrument designed for precision and accuracy in laboratory settings. Featuring a Siedentopf trinocular head that is 30° inclined, and a wide field eyepiece of WF10x/18, this microscope offers superior viewing comfort and a broad field of vision. With its revolving quadruple objective-carrier revolver, it allows seamless magnification changes, ranging from 4x to 100x using achromatic objectives. The microscope also includes a high-performance Abbe condenser with an N.A. of 1.25, complete with an iris diaphragm and filter for optimal lighting control. The focus is finely tuned with coaxial coarse and fine knobs, offering an impressive range of movement and precision adjustments.
This page provides an overview of the Microscope Trinocular YR0241, including selection criteria, investment factors, operational advantages and maintenance recommendations. The aim is to support an informed decision before requesting a quotation.
This Kalstein model is available for laboratories in Netherlands, with selection criteria adapted to local purchasing, installation and support conditions.
Key factors to consider

Before selecting the Microscope Trinocular YR0241, confirm workflow, available space, required accessories and installation conditions. This prevents oversizing the purchase and helps prepare a more accurate quotation.
In practical applications, the Laboratory Microscope YR0241 is used by researchers and educators to closely observe biological specimens, assisting in the study of cellular structures and microorganisms. This microscope’s versatility makes it a vital tool in clinics for cytological and pathological examinations.
For the market in Netherlands, evaluation should consider local context such as agro-tech, biotech, EU CE marking and match the product to the real workload of the laboratory.
Market price range

The investment should be evaluated according to configuration, required accessories, installation conditions and available technical support.
The final price may vary according to configuration, accessories, logistics, warranty and territorial availability. Compare the technical sheet with the real laboratory workload before confirming the investment.
In Netherlands, budget comparison should include CE references, 230V/50Hz power conditions, accessories, logistics and after-sales support.
Value for money

Equipment value depends on operational stability, required accuracy, ease of maintenance and accessory availability.
Value for money should be reviewed together with equipment stability, after-sales support, technical documentation and expected service life. A well-matched selection reduces downtime and improves return on investment.
Advantages and disadvantages

In practical applications, the Laboratory Microscope YR0241 is used by researchers and educators to closely observe biological specimens, assisting in the study of cellular structures and microorganisms. This microscope’s versatility makes it a vital tool in clinics for cytological and pathological examinations.
Main advantages include specialized application, integration with laboratory routines and accessory configuration. Limitations may include installation requirements, user training and preventive maintenance to preserve performance.
Expected lifespan based on use and maintenance

To maximize the microscope’s lifespan and performance, regularly clean the optical lenses with suitable lens cleaning tools and store it in a clean, dry place. It is recommended to undergo a brief calibration and maintenance session every few months or as needed.
Service life depends on usage frequency, cleaning, storage, calibration when applicable and adherence to technical recommendations. A structured maintenance plan helps preserve accuracy, safety and operational continuity.
Support and spare-parts availability oriented to Netherlands helps preserve service continuity and plan preventive maintenance without extended downtime.
Specifications table for the Microscope Trinocular YR0241

Microscope Trinocular YR0241
- Perilla coaxial gruesa y fina, rango de movimiento de 24 mm, división fina de 0,004 mm
- Cabeza trinocular Siedentopf, inclinada a 30°, distancia interpupilar 55-75mm
- Revólver portaobjetivos cuádruple hacia atrás
Especificaciones Técnicas
| Model | YR0241 (current) | |
| Head | Siedentopf binocular head, inclined at 30°, interpupillary distance 48-75mm | ● |
| Siedentopf trinocular head, inclined at 30°, interpupillary distance 55-75mm | ||
| Eyepiece | Wide field eyepiece WF10x/ 18 | ● |
| Objective | Achromatic objective 4x | ● |
| Achromatic objective 10x | ● | |
| Achromatic objective 40x | ● | |
| Achromatic objective 100x | ● | |
| Revolving Nosepiece | Quadruple revolving nosepiece backward | ● |
| Stage | Double layer mechanical stage 132x142mm/ 75x40mm | ● |
| Focusing | Coaxial coarse and fine knob, movement range of 24 mm, fine division of 0.004 mm | ● |
| Condenser | Abbe condenser NA1.25 with iris diaphragm and filter | ● |
| Illumination | LED 3W, adjustable brightness | ● |
| Optional Accessories | Item No. | |
| Eyepiece | P16x/11 | YR0241-op1 |
| Phase contrast kit | YR0241-op2 | |
| Polarization accessory | YR0241-op3 | |
| Illumination | 6V/ 20W halogen lamp, adjustable brightness | YR0241-op4 |
| Dark field condenser | YR0241-op5 | |
Products related to model YR0241

Multi Viewing Research Laboratory Microscope YR06688
Ver producto
Laboratory Microscope YR06686
Ver producto
Biological Microscope YR06685
Ver producto
LCD Digital Biologcal Microscope YR06684
Ver producto
Biological Microscope YR06685
Ver producto
Laboratory Biological Microscope YR06683
Ver producto
Inverted Biological Phase Contrast Microscope YR06682
Ver producto
Motorized Forensic Comparison Microscope YR06681
Ver productoFrequently Asked Questions about the Microscope Trinocular YR0241
What are the main applications of the YR0241 microscope?
The YR0241 is ideal for biological, educational, and clinical settings, offering versatile capabilities for various microscopic examinations.
Is the LED illumination adjustable?
Yes, the LED 3W illumination is adjustable, allowing you to control the brightness to suit your viewing needs.
How do I choose the right microscope trinocular yr0241 for my laboratory?
Selection should start from workload, critical technical parameters, available space and frequency of use. Kalstein can support the comparison between operational needs, budget and maintenance requirements to avoid choosing equipment that is oversized or insufficient.
What should I review before requesting a quotation?
Review the model, technical specifications, required accessories, electrical conditions, consumables, delivery timing and installation needs. With this information, the quotation can be prepared more accurately and aligned with the laboratory workflow.
Does Kalstein provide guidance for this type of equipment?
Yes. The commercial and technical team can support product evaluation, explain differences between models, answer application questions and advise on preventive maintenance, spare parts and documentation required for a secure purchase.
What maintenance helps extend the equipment lifespan?
Follow the manufacturer manual, perform regular cleaning, verify calibrations or controls when applicable, avoid workload abuse and keep maintenance records. Stable use and preventive routines reduce failures and improve operational continuity.
